FMG 180x60x120 120 2 100-HT1
Part no.: 10.12.10.00206
Vacuum area gripper with individually activatable suction points
| Length L | 180 (mm) |
| Width B | 60 (mm) |
| Height H | 120 (mm) |
| 120 (mm) | |
| Number of suction plates | 2 |
| Diameter Ds | 100 (mm) |
| Suction cup material | |
| Suction stroke Zs | 7.5 (mm) |
| Cylinder stroke Z | 10 (mm) |
| Lift capacity (horizontal) | 804 (N) |
| Weight | 990 (g) |
| Communication | IO-Link (Class B) |
| Electrical connection | Male connect M12, 5 pol |
| Pressure range (operating pressure) [bar] | 4.0 ... 6.0 bar |
| Operating temperature max. | 50 (°C) |
Design Data
Design Data
| Attribute | Value |
|---|---|
| B | 60 mm |
| d1 | 8 mm |
| d2 | 6 mm |
| Ds | 100 mm |
| H | 120 mm |
| H1 | 136 mm |
| L | 180 mm |
| X1 | 60 mm |
| Y1 | 48 mm |
| Z | 10 mm |
| Zs | 7.5 mm |
Technical Data
Technical Data
| Attribute | Value |
|---|---|
| Number of suction plates | 2 |
| Suction cup material | |
| Communication | IO-Link (Class B) |
| Electrical connection | Male connect M12, 5 pol |
| Pressure range (operating pressure) [bar] | 4.0 ... 6.0 bar |
| Pressure max. | 6 bar |
| Lift capacity (horizontal) | 804 N |
| Operating temperature max. | 50 °C |
| Weight | 990 g |
CAD data
CAD data
Live CAD-Model easy-to-use
After clicking on the download button, you can download the CAD model in various file formats. If the preview is not displayed correctly on this page, please click on the "Reload" button.
Documentation
Documentation
Software
Software
The matching software for this product is available in this section.
| Documentation | Language |
|---|---|
| English |
Available soon
The matrix area gripper will be available from February 2026.
Are you interested? For more information, please fill out our contact form.
Spare parts
VRS-STEC 6x14.410.08.06.00012Sealing plug
| Operating temperature | °C |
| Outside diameter D | 6 (mm) |
| Length L | 14.4 (mm) |
VRS-STEC 8x18.510.08.06.00013Sealing plug
| Operating temperature | °C |
| Outside diameter D | 8 (mm) |
| Length L | 18.5 (mm) |
SUF 100 HT1-60 G1/8-AG10.01.01.15931Flat suction cup (round) for process
safe handling of smooth or slightly
rough surfaces
| Size | 100 |
| Suction cup material | |
| Material hardness [Shore A] | 60 (Shore A) |
| Number of folds | 0 |
Accessories
SUF 50 HT1-60 G1/8-AG10.01.01.15929Flat suction cup (round) for process
safe handling of smooth or slightly
rough surfaces
| Size | 50 |
| Suction cup material | |
| Material hardness [Shore A] | 60 (Shore A) |
| Number of folds | 0 |
ASK B-M12-5 1000 S-M12-521.04.05.00158Connection cable
| Pressure range (operating pressure) [bar] | bar |
| Electrical connection | Fem connect M12, 5 pol |
| Cable length | 1000 (mm) |
| Connection 2 | |
| Material hose |
ASK B-M12-5 2000 S-M12-521.04.05.00211Connection cable
| Pressure range (operating pressure) [bar] | bar |
| Electrical connection | Fem connect M12, 5 pol |
| Cable length | 2000 (mm) |
| Connection 2 | |
| Material hose |
ASK B-M12-5 5000 S-M12-521.04.05.00266Connection cable
| Cable length | 5000 (mm) |
| Connection 2 | |
| Material hose |
VSL 6-4 PU MI-TR10.07.09.00002Hose for vacuum and
compressed-air systems
| Outside diameter D | 6 (mm) |
| Internal diameter d | 4 (mm) |
| Length max. | 500 (m) |
| Material hose | |
| Bending radius min. | 35 (mm) |
| Pressure range (operating pressure) [bar] | -0.95 ... 10.00 bar |
| Operating temperature | -20 ... 90 °C |
| Color | Milky-transparent |
VSL 8-6 PU MI-TR10.07.09.00003Hose for vacuum and
compressed-air systems
| Outside diameter D | 8 (mm) |
| Internal diameter d | 6 (mm) |
| Length max. | 500 (m) |
| Material hose | |
| Bending radius min. | 45 (mm) |
| Pressure range (operating pressure) [bar] | -0.95 ... 10.00 bar |
| Operating temperature | -35 ... 60 °C |
| Color | Milky-transparent |
